HDMI Touch Display 10.1 Inch 1280x800 IPS TFT Lcd Module with PCB Driver Board

Product Description:

The CH101WX05C-CT is a 10.1-inch TFT LCD display module featuring an IPS panel with a resolution of 800x1280 pixels. It offers a wide viewing angle of 80 degrees from all directions, ensuring consistent and clear image quality regardless of the user’s perspective. The display operates in a transmissive mode with a normally black background, which helps improve contrast and readability in various lighting conditions. The module integrates a capacitive touch panel (CTP) with a glass lens thickness of 1.1mm and supports multi-touch functionality, enhancing user interaction and control. This display module is equipped with a white LED backlight delivering a luminance of 300 cd/m², suitable for indoor applications where moderate brightness is required. The TFT dot pitch is 0.1692 mm in both width and height, contributing to sharp and detailed image rendering. The active display area measures 135.36 mm by 216.576 mm, providing ample screen space for diverse applications. The CH101WX05C-CT module comes with an HDMI interface board sized 46x50x5 mm, allowing easy connectivity with various devices such as Windows, Linux, MAC OS, and Raspberry Pi platforms. The touch panel interface uses USB (DC 5V) power supply, simplifying integration and power management. This combination of HDMI display and capacitive touch makes it ideal for interactive systems requiring high compatibility and ease of use. Designed with a compact outline size of 143.4 mm by 228.9 mm and a total thickness of 4.45 mm including PCBA and components, the module is lightweight and slim, suitable for embedded systems and portable devices. The robust construction includes layers such as glass sensor, SCA, and foam padding to ensure durability and reliable touch sensitivity.

Features:

Compact and Slim Outline Dimensions
The CH101WX05C-CT module features a compact outline size of 143.4 mm in width, 228.9 mm in height, and a total thickness of 4.45 mm including the PCBA and components. This slim profile makes it suitable for integration into space-constrained applications such as portable devices and embedded systems where minimizing bulk is essential.

High-Resolution Display
This display module offers a resolution of 800 (RGB) x 1280 pixels, delivering clear and detailed images. The pixel arrangement ensures vivid color representation and sharp visuals, which is beneficial for applications requiring precise image rendering, such as medical devices and industrial control panels.

Versatile Interface Support
Equipped with an HDMI interface board and a USB-powered capacitive touch panel, the CH101WX05C-CT supports easy connectivity with a variety of operating systems including Windows, Linux, MAC OS, and Raspberry Pi. The HDMI interface allows for high-quality video transmission, while the USB interface simplifies touch panel integration and power supply management.

Wide Viewing Angle
The module provides a consistent viewing experience with an 80-degree viewing angle in all directions (up, down, left, right). This wide viewing angle ensures that the display maintains good color accuracy and contrast even when viewed from off-center positions, which is important for collaborative environments and multi-user applications.

Technical Parameters:

Customization:

The CH101WX05C-CT display module offers a flexible customization process tailored to meet specific project requirements in the TFT LCD industry. Customization begins with understanding the buyer’s application needs, including desired display size, resolution, interface type, and environmental conditions. For this 10.1-inch IPS panel with a resolution of 800x1280 pixels, customers can request modifications in several key areas to optimize performance and integration.

One common customization aspect is adjusting the module’s mechanical dimensions and outline to fit unique device enclosures or mounting constraints. The CH101WX05C-CT’s slim profile and compact size can be further tailored by modifying the thickness or the shape of the glass lens and touch panel layers. This ensures seamless integration into products such as industrial control panels, medical devices, or vehicle-mounted systems where space is limited.

Interface customization is another critical area. While the standard module includes an HDMI interface and USB-powered capacitive touch panel, customers may require alternative interface configurations such as MIPI, RGB, or LVDS depending on their hardware ecosystem. Chenghao Optoelectronic supports defining or redesigning the LCD interface and touch panel interface to match specific controller boards or operating systems, enhancing compatibility and reducing development time.

Backlight brightness and color calibration can also be customized to suit different lighting environments. The CH101WX05C-CT’s white LED backlight with 300 cd/m² luminance can be adjusted upward for outdoor or high ambient light conditions or tuned for power-saving in battery-operated devices. Additionally, touch panel features like multi-touch support, touch feedback, and anti-glare coatings can be customized to improve user experience based on application scenarios.

The customization process typically involves close collaboration between Chenghao’s engineering team and the customer. After initial requirements are gathered, prototypes are developed and tested to ensure all specifications are met. This iterative process helps address any technical challenges and ensures the final product aligns perfectly with the customer’s functional and aesthetic demands. Chenghao’s ability to offer one-stop solutions—from design and prototyping to mass production—makes the CH101WX05C-CT a versatile choice for customized TFT LCD applications .
